Sunrui has full abilities of design, production, assembly and commissioning in electro{{0}}Chlorination system. According to customer's requirements and actual conditions, it can provide the system of active chlorine production with 0.1Kg1000Kg/h by seawater electrolysis.
Sunrui has depended on State Key Laboratory for Marine Corrosion and Protection with it's four marine experiment stations of Qingdao, Xiamen, Snaya and Deep-sea to do experiments and research. Sunrui has set up research and development department in charge of developing new products, new technologies and achievements. Sunrui has independent intellectual property rights of major technologies and products to promote the development of chlorine electrolysis industry with providing technology reserve ans support.
Sunrui has modern workshops of 26000 square meters, highly qualified and skilled workers, advanced production technology, dozens of producing and testing equipment, standardized management system and first-class testing conditions. Because of using the method of "Production and Inspection", Sunrui could improve the acceptability of products and provide guarantee for the quality of products. The annual production capacity of electrolytic chlorine system is 10000Kg/h.
Quality Assurance
● DSA anode has a continuous running life of over 5 years
● Hastelloy alloy has a life assurance of over 40 years
● Stable electricity controller with special design
High efficient and Energy saving
● DSA anode, high electrolytic efficiency
● Special structure of electrolytic cell, convenient to manage
● Hastelloy alloy cathode, avoid embrittlement and save energy
High Safety and Reliability
● No chlorine gas leaking
● PLC control, no staff duty
● Various safe structures of hydrogen removal
Application Industry
● Nuclear power plant
● Thermal power plant
● Petrochemical plant
Typical Medels of Plate-mesh Type Electrolyzer
Seawater Condition | Seawater Condition | Seawater Condition | Sodium Hypochlorite | |||||
Model | 5＜T＜10 degree | 10＜T＜15 degree | 15＜T＜34 degree | ppm | ||||
Minimum | Maximum | Minimum | Maximum | Minimum | Maximum | Minimum | Maximum | |
2-HE401 | 1 | 2 | 2 | 3 | 3 | 4 | 300 | 500 |
2-HE602 | 1 | 3 | 3 | 5 | 5 | 5 | 500 | 1000 |
2-HE603 | 4 | 8 | 10 | 13 | 14 | 16 | 500 | 1000 |
2-HE604 | 6 | 12 | 14 | 20 | 21 | 23 | 500 | 1000 |
3-HE604 | 9 | 18 | 21 | 30 | 32 | 35 | 500 | 1000 |
2-HE805 | 8 | 16 | 18 | 26 | 28 | 30 | 500 | 1000 |
3-HE805 | 12 | 24 | 28 | 39 | 41 | 45 | 500 | 1000 |
2-HX075 |
|
| 8 | 12 | 13 | 15 | 750 | 1500 |
2-HX150 |
|
| 16 | 24 | 27 | 30 | 750 | 1500 |
2-HX300 |
|
| 32 | 48 | 54 | 61 | 750 | 1500 |
2-HX400 |
|
| 44 | 67 | 75 | 85 | 750 | 1500 |
3-HX075 |
|
| 12 | 18 | 20 | 23 | 750 | 1500 |
3-HX150 |
|
| 24 | 36 | 40 | 46 | 1000 | 1800 |
3-HX300 |
|
| 48 | 71 | 81 | 91 | 1000 | 2000 |
3-HX400 |
|
| 67 | 100 | 113 | 128 | 1000 | 2000 |
2-VE805 |
|
|
|
| 76 | 86 | 1200 | 2000 |
2-VEX05 |
|
|
|
| 95 | 108 | 1500 | 2000 |
2-VE810 |
|
|
|
| 153 | 174 | 1200 | 2000 |
2-VEX10 |
|
|
|
| 191 | 217 | 1500 | 2000 |
3-VE805 |
|
|
|
| 114 | 129 | 1500 | 2000 |
3-VEX05 |
|
|
|
| 143 | 162 | 1500 | 2000 |
3-VE810 |
|
|
|
| 230 | 260 | 1500 | 2000 |
3-VEX10 |
|
|
|
| 287 | 325 | 1500 | 2000 |
4-VEX10 |
|
|
|
| 383 | 434 | 1500 | 2000 |
